Ceph Operations Guide

Installation (Helm)

1. Add the Rook Helm repository:

   helm repo add rook-release https://charts.rook.io/release

2. Install the operator:

   helm install --create-namespace --namespace rook-ceph rook-ceph rook-release/rook-ceph -f values.yaml

3. Install the cluster:

   helm install --create-namespace --namespace rook-ceph rook-ceph-cluster --set operatorNamespace=rook-ceph rook-release/rook-ceph-cluster -f values.yaml

Operator Configuration

Default Values for rook-ceph-operator

• Pod Resource Requests & Limits:

  resources:
    requests:
      cpu: 20m

• Global Log Level:

  logLevel: INFO

• CSI Configuration:

  • RBD Provisioner Resources:

    csiRBDProvisionerResource: |
      - name: csi-provisioner
        resource:
          requests:
            cpu: 10m
      ...

  • RBD Plugin Resources:

    csiRBDPluginResource: |
      - name: driver-registrar
        resource:
          requests:
            memory: 128Mi
            cpu: 5m
          limits:
            memory: 256Mi
      ...

  • CephFS Provisioner and Plugin Resources (similar format).

  • NFS Provisioner and Plugin Resources (similar format).

• Monitoring:

  monitoring:
    enabled: true

Cluster Configuration

• Toolbox:

  toolbox:
    enabled: true
    resources:
      requests:
        cpu: '10m'

• Ceph Cluster Specifications:

  cephClusterSpec:
    dashboard:
      port: 7000
    labels:
      monitoring:
        release: prometheus-stack
    resources:
      mgr:
        requests:
          cpu: "50m"
      mon:
        requests:
          cpu: "100m"
      ...
    removeOSDsIfOutAndSafeToRemove: true

Removing OSDs

1. Stop the Rook Operator:

   kubectl -n rook-ceph scale deployment rook-ceph-operator --replicas=0

2. Mark OSD as out:

   ceph osd out osd.<ID>

3. Confirm OSD is down:

   kubectl -n rook-ceph scale deployment rook-ceph-osd-<ID> --replicas=0
   ceph osd down osd.<ID>

4. Wait for backfilling to complete (active+clean PGs).

5. Remove the OSD:

   ceph osd purge <ID> --yes-i-really-mean-it
   ceph auth del osd.<ID>
   ceph osd crush remove <nodeName>

6. Verify:

   ceph osd tree

7. Restart the Rook Operator.

Disk Partitioning

1. List available disks:

   sudo fdisk -l

2. Partition a disk:

   sudo fdisk /dev/sda
   # Use `n` to create and `w` to save.

Clearing Devices

1. Clear partitions:

   sgdisk --zap-all $DISK
   dd if=/dev/zero of="$DISK" bs=1M count=100 oflag=direct,dsync

Exposing Monitoring GUI

1. Certificate Definition (Cert Manager):

   apiVersion: cert-manager.io/v1
   kind: Certificate
   metadata:
     name: ceph-sololude-certificate
     namespace: istio-ingress
   spec:
     secretName: ceph-ingress-cert
     commonName: ceph.sololude.com
     dnsNames:
       - ceph.sololude.com
     issuerRef:
       name: sololude-issuer

2. Gateway Definition (Istio):

   apiVersion: networking.istio.io/v1beta1
   kind: Gateway
   metadata:
     name: rook-ceph-dashboard-gw
     namespace: rook-ceph
   spec:
     selector:
       app: istio-ingressgateway
     servers:
       - port:
           number: 443
           name: https-ceph
           protocol: HTTPS
         hosts:
           - ceph.sololude.com
         tls:
           mode: SIMPLE
           credentialName: ceph-ingress-cert
       - port:
           number: 80
           name: http-ceph
           protocol: HTTP
         hosts:
           - ceph.sololude.com

3. Virtual Service Definition (Istio):

   apiVersion: networking.istio.io/v1
   kind: VirtualService
   metadata:
     name: ceph-gateway-vs
     namespace: rook-ceph
   spec:
     hosts:
       - ceph.sololude.com
     gateways:
       - rook-ceph-dashboard-gw
     http:
       - route:
           - destination:
               host: rook-ceph-mgr-dashboard

Issues and Troubleshooting

1. Service Port Change:

   • Set cephClusterSpec.dashboard.port=7000 in Helm values.

2. OSD Keyring Mismatch:

   • Retrieve keyrings and resolve mismatch.

3. Entity Exists with Key Mismatch:

   • Delete older auth:

     ceph auth del osd.x

Monitoring

• Enable monitoring in Helm values:

  monitoring:
    enabled: true

• Add labels for monitoring:

  cephClusterSpec.labels.monitoring={release: prometheus-stack}

Upgrade

1. Upgrade Helm:

   curl https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3 | bash

2. Upgrade using Helm:

   helm upgrade -n rook-ceph rook-ceph rook-release/rook-ceph -f values.yaml
